Fully Automatic 100-1800kg/H Cracker Hard And Soft Biscuit Production Line

Products Description

Fully Automatic Industrial Cracker Biscuit Making Biscuit Making Machine

Soft And Hard Biscuit Production Line

Machine component:

1. Gauge roller diameter 300-350mm, Feeding roller diameter 350mm
2. Schneider inverter&transducer and PLC touch screen control
3. Schneider electronic from France
4. Main driver by Chinese Famous Guomao Brand motor & gearbox
5. Main bearing use NSK from Japan
6. AirTAC Penumatic cylinder for belt tension and deflecting adjustment
7. PU belt from Heland Ammeraal Beltech brand 1.2-1.5mm thickness
8. Main machines 304 Stainless steel cover, thickness 1.2-1.5mm; oven cover 304 stainless
9. Air cylinder use AirTAC
10. All power-roller for convey belt use food grade, oil-resistance rubber roller

Process

Fully Automatic 100-1800kg/H Cracker Hard And Soft Biscuit Production Line

STEP 1

Horizontal Dough Mixer and dough Tub

*Speed from 25r/min to Max. Speed60r/min, frequency speed
*Germany Famous brand SEW motor & gearbox
*Full stainless steel 304#
with one Dough Tub capacity 150kgs.
*Tub thickness 5mm and 8mm.
*Newest design touch screen Siemens PLC control system.

STEP 2

Automatic dough tipper and feeding system

This system has included one small dough truck, automatic tipper, one dough cutting and transport machine, and soft dough conveyor belt

.*Gearbox use GUOMAO BRAND brand

*GUOMAO BRAND motor, High efficiency, low noise and long using life and so on.

*PU conveyor belt with baffle groove to carry small pieces dough

*Cutting controlled by air pneumatic, AirTac air cylinder.

*Main driver use direct drive, NSK bearing from Japan

*Electronic element use Schneider brand

STEP 3

Three-roll Combination Sheeter

*Double groove feeding rollers

*PU conveyor belt, thickness 1mm

*Gearbox use GUOMAO BRAND brand, bevel
wheel with high drive efficiency, low noise and work stability and so on.

*Motor: GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.

STEP 4

Horizontal Laminator

Stainless steel, Support roller, transition scraper covered hard chrome

Main driver use double rows chain, NSK bearing from Japan

Electric control: All driving speed controlled by frequency conversion

Transducer and Electronic element use Schneider brand

Laminating width 1000mm, 4-12layers, sheeting dough thickness 0-10mm, included crisp spreader machine Power: 4.5KW,
Dimension: 2620x1330x2080mm

Weight: 2500kg

STEP 5

Gauge Roll Sheeting Group (1st, 2nd and 3rd)

*Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency, low noise and work stability and so on. Motor:

*GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.

*High quality alloy steel Sheeting rolls and Conveyor belt controlled by one motor

STEP 6

Rotary Cutter(for hard biscuit)

*Embossing in one roller and cutting in one roller, PU conveyor belt, thickness 1mm,

*Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency, low noise and work stability and so on. Motor

*GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.

*Two rubber rolls diameter 220mm for cutting, two rubber rolls diameter 160mm for cotton conveyor belt.

STEP 7

Rotary Moulder(for soft biscuit)

*Double driver, rubber rolls and forming mould has different motor driver PU conveyor belt, thickness 1mm

*Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency, low noise and work stability and so on. Motor:

*GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.

STEP 8

Separation Machine

*Transition scraper covered hard chrome, Scrap tray and cover made by 304 stainless
steel, 1.2mm thickness

* Main driver use chain drive, NSK bearing from Japan, Electric control: All driving speed controlled by frequency conversion *Transducer and Electronic element use *Schneider brand Working width 1000mm, sheeting dough thickness 0-20mm
*Power: 2.5KW

* Dimension: 1860x1320x1020mm

*Total weight: 650kg

STEP 9

Enter stove machine

*Cotton conveyor belt, thickness 1.5mm

*The belt tension and deflection adjusted by Air pneumatic

* Air cylinder AirTAC brand

*Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency, low noise and work stability and so on.

*Motor: GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.

STEP 10

Tunnel oven

Electric baking oven is used electricity as energy. It’s high efficiency, long usage, easy maintenance.
Gas baking oven is used natural gas as energy. It’s more scientific and safe, high efficiency rapid heating, save energy, clean and simple operation.

Model	length of oven(30-60m)	Capacity
400mm	16-40m	100-200kgs
600mm	50m	200-400kgs
800mm	50-60m	400-600kgs
1000mm	50-60m	600-800kgs
1200mm	65m	800-1000kgs

STEP 11

Biscuit stacking machine

One is Star wheel structure, it is composed by transition conveyor, divided biscuits in order rows and stacking, total two conveyor belts.
The other is Panny Biscuit stacker, usually it combined by 3 units of different speed conveyors, the speed from fast to slow,through discrepancy speed to make the biscuits lay down as lines, to easy transport to packaging machine.

Sample

Rotary Cutter Mold

Can customized for you

Hard BIscuit

Rotary Moulder Mold

Can customized for you

Soft Biscuit

Certifications

Our machines was approve Certificate of CE certificate, Utility Model Utility Patents and Certificate of Design Patent. We obtained 12 National Patent, 8 for biscuit machine and 4 for sandwich biscuit machine connected packing system.

Company Introduction

SKYWIN Food Machinery Group Company was Founded in 2010,which is lotated in Beijiao, Shunde, Foshan, Guangdong, CHINA Foshan City is stainless steel Birthplace.
Skywin Group has two factories, one is for Large Biscuit & Cookies & Wafer production line, one is for Automatic Biscuit sandwiching machine with Packing system. We have more than 60 professional staffs to match delivery time, base on “International Quality, Competitive Price”.

After Sales Service

Packing&Shipping

Step 1: Mechanical surface coated with preservative solution (to protect stainless steel).
Step 2: The plastic cushion packing machine (prevent bump).
Step 3: Plastic film packaging (to prevent ventilation).
Step 4: Wooden case / frame packaging (easy to transport).
Step 5: Tie the bandage outside of the wooden case (reinforcement overall).
