2021Skywin Industrial Horizontal Dough Mixer Machine for Mixing Biscuit Flour Price

This dough mixer machine is suitable for mixing flour dough for biscuit and cake production, cream mixing and etc.
The equipment is used for dough mixing, after the kneading,rolling and folding process, Dough has a smooth surface with good elasticity, toughness and extensibility. It is suitable for both hard and soft biscuits.

The mixing blade and bucket are made of 304 Stainless steel, U-form bucket has temperature insulation function, simple operation and safety.

The mixing bearing is designed that seal is separated from the bearing to prevent the grease from contaminating the dough in case of broken seal.

Specification of Dough Mixer :
Horizontal Dough Mixer (Model WH50S)
1. Model HMS-50
2. Capacity: 50kg per batch, 5-6bags flour per batch
3. Multi mixing speed: low speed 25rpm/min and high speed to 50rpm/min
4. Double jacket bowel to control dough temperature
5. Mixing blade is 304 Stainless steel
6. Bowl covered by 304 Stainless steel
7. Machine Cover made by 304 Stainless steel
8. Main driver Chinese famous brand Guomao ,optional SEW motor
9. Siemens electric and PLC touch screen control
10. Main bearing use NSK
11. Tipping by Hydraulic pressure
12. Total Motors: 2pcs
13. Gear Box: 2pcs
14. Power: 15kw and 7kw
15. Gross Weight: 300kgs

From 50kg to 750kg

Horizontal and Vertical as you required.

We have horizontal mixer 50kg,150kg,250kg,500kg,750kg

We also have Vertical type dough mixer

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Step 1: Mechanical surface coated with preservative solution (to protect stainless steel).
Step 2: The plastic cushion packing machine (prevent bump).
Step 3: Plastic film packaging (to prevent ventilation).
Step 4: Wooden case / frame packaging (easy to transport).
Step 5: Tie the bandage outside of the wooden case (reinforcement overall).
