    Semi Automatic Cookie Production Line Forming Part Small Cookie Making Machine

    Ask Lasest Price
    Brand Name : SKYWIN
    Model Number : SK-Cookie-400
    Certification : CE ISO
    Price : US $8,500~12,500/Set
    Supply Ability : 2 Set/Sets per Month
    Delivery Time : 25-30 work days
    • Product Details
    • Company Profile

    Semi Automatic Cookie Production Line Forming Part Small Cookie Making Machine

    Production process


    Dough making → Biscuit forming → Baking → Cooling → Stacking→ Packing

    The parameters:

    NameSKYWIN Tray type Cookie Making Machine
    Capacity50-150kgs/H
    Tray Size600long x400wide mm

    Voltage

    Power

    380V/220V/50Hz

    1.5KW

    Conveyorcircinate woven belt
    Cover304 Stainless Steel
    MotorSEW motor and speed reducer,
    Frequency TransformerSIEMENS
    Electric Control SystemSIEMENS touch screen ,PLC and control unit
    BearingNSK
    Air CylinderFESTO
    N.W.450kgs
    Model NoSK400

    Advantage:

    1. To fixed tray size 400mm wide x 600mm long
    2. Stainless steel Cover, thickness 1.5mm
    3. Rubber roll diameter 122mm(endless cotton belt driver)
    4. PVC conveyor belt, thickness 2mm

    5. Feeding roll diameter 106mm, with groove
    6. Speed about 60 times/min, frequency conversion controlled

    7. Extrusion/depositor about 30 stroke one minute
    8. Cutter about 40 stroke one minute
    9. Both wire cut and deposit
    Parameter:
    1. Provided two sets of cookies moulds,
    2. one set wire cut and one set of deposit
    3. Chinese brand electric parts Chinese brand motor & gearbox
    4. Voltage: 380V/220V/50Hz Power 1.5kw
    5. Machine dimension: 1330*900*1340mm Weight: 450kgs

    Semi Automatic Cookie Production Line Forming Part Small Cookie Making Machine

    Semi Automatic Cookie Production Line Forming Part Small Cookie Making MachineSemi Automatic Cookie Production Line Forming Part Small Cookie Making Machine

    Semi Automatic Cookie Production Line Forming Part Small Cookie Making Machine

    Semi Automatic Cookie Production Line Forming Part Small Cookie Making Machine

    Semi Automatic Cookie Production Line Forming Part Small Cookie Making Machine


    OUR SERVICE:

    Pre-Sales Service

    * Inquiry and consulting support.

    * Any time welcome to view our factory.

    * Bring your sample test in our machine.

    * Check the quality and device.


    After-Sales Service

    * Training how to instal the machine, training how to use the machine.

    * Engineers available to service machinery overseas.

    * Provide the solution within 2 hours.

    * Engineers can speaking english to help.

    Packaging & Delivery


    Packaging Details: Wooden Packing as Export Standard of Customized Automatic Ice Cream Sugar Cone Biscuit Production Line Machine


    Port: Any Port of China

    Semi Automatic Cookie Production Line Forming Part Small Cookie Making Machine


    Company Information:

    Skywin Foodstuff Machinery Co.,Ltd. was established in 2010 as a manufacturer, which specialized in biscuit production lines and cookie production lines and wafer biscuit production lines.

    Skywin provide one-stop solution and service from biscuit production to biscuit sandwiching, biscuit chocolate enrobing and biscuit packing. Fully automatic by PLC control.


    We will supply professional consulting services used in the industry of biscuit production, as well as the most suitable design proposal and quality machines.


    If you are interested in the machine, please feel free to contact us, we will provide professional information and provide a suitable proposal for you.
